BIRCOlight
Ductile iron double slotted gratings
+ 2-point per metre bolt connection M12/A2
+ 2-point per metre Easylock-fastening (alternatively)
+ Anti-slip classification R11/V10
black immersion-lacquered
| Designation | Article No. | Ext. dimensions L [mm] | Ext. dimensions W [mm] | Ext. dimensions W [mm] | Slot width L [mm] | Slot width B [mm] | Maschenweite L [mm] | Maschenweite B [mm] | Inlett-cross-section [cm²/m] | Load class up to (EN 1433) | Weight [kg] | PG | Pallet [Quantity] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| light 100 black double slot iron grate | 0210721 | 500.00 | 153.00 | 21.00 | 45.00 | 16.00 | 0.00 | 0.00 | 444.00 | C 250 | 3.40 | 2102 | 100.00 |
| light100 black cast iron grate easylock | 0210721e | 500.00 | 153.00 | 21.00 | 45.00 | 16.00 | 0.00 | 0.00 | 444.00 | C 250 | 3.40 | 2102 | 100.00 |
| light 100 black double slot iron grate | 0210751 | 500.00 | 153.00 | 21.00 | 45.00 | 16.40 | 0.00 | 0.00 | 444.00 | E 600 | 3.80 | 2102 | 100.00 |
| BIRCOlight 100 AS cast iron grate | 0210751e | 500.00 | 153.00 | 21.00 | 45.00 | 16.40 | 0.00 | 0.00 | 444.00 | E 600 | 3.80 | 2102 | 100.00 |
